Daikin UAT700AMY1 [14/43] Capacity tables
![Daikin UAT700AMY1 [14/43] Capacity tables](/views2/1694833/page14/bge.png)
3
1
7
• Rooftops • Cooling only
10
• Cooling only • R-22 • UAT-AMY1
7 Capacity tables
7 - 1 Cooling capacity tables
SELECTION PROCEDURE
PERFORMANCE DATA
Performance table
Interpolation and extrapolation method can be used to get the total capacity, Q and sensible capacity, SC at those temperatures which are not stated
out in the table.
Example:
Model: UAT700AY1
Indoor Condition: 23°C DB, 15°C WB
Outdoor condition: 37°C DB
Solution:
Overall
Based on the Performance table of UAT700AY1,
1. Refer to the indoor DB Column,
- 23°C is located between 20°C and 24°C (Thus, Interpolation need to be applied)
2. Refer to the indoor WB Column,
- 15°C only available in the case of indoor DB = 20°C. (Thus, extrapolation between 16°C WB and 17°C WB during 24°C indoor DB is required)
3. Refer to the indoor DB Column,
- 37°C is located between 35°C and 40°C. (Thus, Interpolation need to be applied)
Please follow the steps below in order to get the required capacity.
1
st
STEP
Extrapolation of indoor WB
Find Q, SC for
(a) Indoor: 24°C DB,
15°C WB
Outdoor: 35°C DB
(b) Indoor: 24°C DB,
15°C WB
Outdoor: 40°C DB
➩
2
nd
Step
Extrapolation of indoor WB
Find Q, SC for
(a) Indoor:
23°C DB,
15°C WB
Outdoor: 35°C DB
(b) Indoor:
23°C DB
, 15°C WB
Outdoor: 40°C DB
➩
3
rd
STEP
Extrapolation of indoor WB
Find Q, SC for
(a) Indoor: 23°C DB, 15°C WB
Outdoor:
37°C DB
