Daikin UAT700AMY1 [17/43] Capacity tables
![Daikin UAT700AMY1 [17/43] Capacity tables](/views2/1694833/page17/bg11.png)
• Cooling only • R-22 • UAT-AMY1
1
7
• Rooftops • Cooling only
13
7 Capacity tables
7 - 1 Cooling capacity tables
3
rd
Step:
To obtain the Total capacity and Sensible capacity for
(a) Indoor Condition:
23°C DB
,
15°C WB
Outdoor Condition:
37°C DB
Total capacity, Q
Interpolation method:
40°C - 35°C 59.831kW - 64.922kW
➩
=
40°C-37°C 59.831kW - x
➩
y = 62.886 kW
Sensible capacity, SC
Interpolation method:
40°C - 35°C 42.728kW - 46.857kW
➩
=
40°C - 37°C 42.728kW - y
➩
y = 45.205 kW
Indoor DB
°C
Indoor WB
°C
Outdoor DB°C
35 37 40
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
!!
23 15 64.922 46.857 x y 59.831 42.728
