100W Constant Voltage + Constant Current LED Driver
HLG-100H series
※ Waterproof connector
Waterproof connector can be assembled on the output cable of HLG-100H to operate in dry/wet/damp or outdoor environment.
LED Lamp
※ Cable Joiner
※ Junction Box Option
Pin Configuration (Female) Pin Configuration (Female)
Size Size
M12 M15
4-PIN
5A/PIN
M12-04Order No. Order No.
10A max.Suitable Current Suitable Current
5-PIN
5A/PIN
M12-05
10A max.
2-PIN
12A/PIN
M15-02
12A max.
Up to four wires can be connected through this cable joiner by
soldering or clamping by tools.
66
26
20
ψ25
CJ04-2 suitable for 18AWG~22AWG
CJ04-1 suitable for 14AWG~16AWG
LED Lamp
WATERPROOF CONNECTION
◎ CJ04 cable joiner can be purchased independently for user's own assembly.
MEAN WELL order No. : CJ04-1, CJ04-2.
◎ A / Blank - TypeJunction box option is available for . Please contact MEAW WELL for details.
HLG-100H
I/P
O/P
AC
source
O/P Wires
HLG-100H
File Name:HLG-100H-SPEC 2018-09-30
Please refer to:http://www.meanwell.com/manual.html
INSTALLATION MANUAL
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
150 20±
3- PF 1/2"
86
76
5
10
38.8
35
2- 5ψ
61
32
8.58.5
6
196
358
150 20±
3- PF 1/2"
68
SJOW 17AWG&
05RN-F 1.0mm *2C
2
-V(Black)
+V(Red)
SJOW 17AWG&
H05RN-F 1.0mm *3C
2
