※AB-Type
Tcase
tc
File Name:HLG-100H-SPEC 2018-09-30
: Max. Case Temperature
tc
100W Constant Voltage + Constant Current LED Driver
HLG-100H series
Vo
ADJ.
Io
ADJ.
300 20±
38.8
220
196
12
9.6
9.49.4 34.2
68
ψ×4.2 4PL
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
98
34
-V(Black)
+V(Red)
SJOW 17AWG&05RN-F 1.0mm *2C
2
※B-Type
Tcase
tc
: Max. Case Temperature
tc
300 20±
38.8
220
196
12
9.6
9.49.4 34.2
68
ψ×4.2 4PL
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
98
34
-V(Black)
+V(Red)
DIM-(White)
DIM+(Blue)
UL2517 20AWG*2C
SJOW 17AWG&05RN-F 1.0mm *2C
2
SJOW 17AWG&H05RN-F 1.0mm *3C
2
SJOW 17AWG&H05RN-F 1.0mm *3C
2
DIM-(White)
DIM+(Blue)
UL2517 20AWG*2C
