Case No.994 Unit:mm
150W Constant Current Mode LED Driver
HLG-120H-C series
File Name:HLG-120H-C-SPEC 2018-09-30
※ B-Type
※ A-Type
MECHANICAL SPECIFICATION
: Max. Case Temperature
tc
tc
300 20±
FG (Green/Yellow)
SOOW 17AWG H07RN F 1 0mm 2C&-.ײ
(for HLG-120H-C350)
SJOW 17AWG H07RN F 1 0mm 2C(for others)&-.ײ
38.8
SJOW 17AWG H05RN F 1 0mm 3C&-.ײ
220
196
AC/L(Brown)
AC/N(Blue)
12
9.6
9.49.4 34.2
68
ψ×4.2 4PL
300 20±
98
34
Io
ADJ.
300 20±
220
196
12
9.6
9.49.4 34.2
68
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
SJOW 17AWG H07RN F 1 0mm 2C&-.ײ
98
34
ψ×4.2 4PL
38.8
: Max. Case Temperature
tc
tc
SJOW 17AWG H05RN F 1 0mm 3C&-.ײ
SOOW 17AWG H07RN F 1 0mm 2C&-.ײ
(for HLG-120H-C350)
SJOW 17AWG H07RN F 1 0mm 2C(for others)&-.ײ
-V(Blue)
+V(Brown)
DIM-(Black)
DIM+(Gray)
-V(Blue)
+V(Brown)
