Tcase
tc
300 20±
38.8
228
204
12
9.6
9.49.4 34.2
68
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
102
34
Vo
ADJ.
Io
ADJ.
: Max. Case Temperature
tc
185W Constant Voltage + Constant Current LED Driver
HLG-185H series
※AB-Type
File Name:HLG-185H-SPEC 2018-12-17
SJOW 17AWG&H05RN-F 1.0mm *3C
2
ψ×4.2 4PL
(SJOW 14AWG*2C for 12V~15V)
SJOW 17AWG&05RN-F 1.0mm *2C
2
-V(Black)
+V(Red)
Tcase
tc
300 20±
38.8
228
204
12
9.6
9.49.4 34.2
68
300 20±
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
102
34
: Max. Case Temperature
tc
※B-Type
SJOW 17AWG&H05RN-F 1.0mm *3C
2
ψ×4.2 4PL
(SJOW 14AWG*2C for 12V~15V)
SJOW 17AWG&05RN-F 1.0mm *2C
2
-V(Black)
+V(Red)
DIM+(Blue)
DIM-(White)
UL2517 20AWG*2C
DIM+(Blue)
DIM-(White)
UL2517 20AWG*2C
