![MEAN WELL HLG-320H-12A [8/10] Hlg 320](/views2/1696376/page8/bg8.png)
File Name:HLG-320H-SPEC 2019-05-28
320W Constant Voltage + Constant Current LED Driver
HLG-320H series
※Blank/D-Type
MECHANICAL SPECIFICATION
※A-Type
Case No.202A Unit:mm
112.6
112.6
45
45
FG (Green/Yellow)
FG (Green/Yellow)
AC/L(Brown)
AC/L(Brown)
AC/N(Blue)
AC/N(Blue)
300 20±
300 20±
13.4
13.4
8.9
8.9
17
17
40
40
90
90
225.2
225.2
252
252
17
17
Io
ADJ.
Vo
ADJ.
300 20±
300 20±
ψ×4.5 4PL
ψ4.5 4PL×
43.8
43.8
: Max. Case Temperature
: Max. Case Temperature
tc
tc
tc
tc
SJOW 17AWG&H05RN-F 1.0mm *3C
2
SJOW 17AWG&05RN-F 1.0mm *2C
2
(SJOW 14AWG*2C for 12V~30V)
SJOW 17AWG&H05RN-F 1.0mm *3C
2
SJOW 17AWG&05RN-F 1.0mm *2C
2
(SJOW 14AWG*2C for 12V~30V)
+V(Red)
-V(Black)
+V(Red)
-V(Black)
※B-Type
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
112.6
45
300 20±
13.4
8.9
17
40
90
225.2
252
17
43.8
300 20±
ψ×4.5 4PL
: Max. Case Temperature
tc
tc
SJOW 17AWG&H05RN-F 1.0mm *3C
2
SJOW 17AWG&05RN-F 1.0mm *2C
2
(SJOW 14AWG*2C for 12V~30V)
DIM-(White)
DIM+(Blue)
+V(Red)
-V(Black)
UL2517 20AWG*2C
