480W Constant Current Mode LED Driver
HLG-480H-C series
File Name:HLG-480H-C-SPEC 2019-02-28
INSTALLATION MANUAL
Please refer to : http://www.meanwell.com/manual.html
※ Junction Box Option
◎ all typesJunction box option is available for . Please contact MEAW WELL for details.
FG
AC/L
AC/N
Vo+
Vo-
3- PF 1/2" 3- PF 1/2"
76
5
10
6
397.2
235.2
86
125
150 20±
150 20±
43.8
35
2- 5ψ
61
32
8.5
8.5
※AB-Type
SJOW 17AWG 3C H05RN-F××& 3 1.0mm
2
SJOW 17AWG 2C H05RN-F××& 2 1.0mm
2
113.8
58
tc
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
300 20±
ψ×4.5 4PL
SOOW 17AWG 2C H07RN-F××& 2 1.0mm
2
300 20±
330 20±
: Max. Case Temperature
tc
8.9
15
15
78
125
13.4
235.2
262
43.8
Vo-(Blue)
Vo+(Brown)
DIM-(Black)
DIM+(Gray)
Io
ADJ.
