MECHANICAL SPECIFICATION
Case No. 251 Unit:mm
※A-Type
※B/D2-Type
480W Constant Current Mode LED Driver
HLG-480H-C series
File Name:HLG-480H-C-SPEC 2019-02-28
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
SJOW 17AWG 3C H05RN-F××& 3 1.0mm
2
SJOW 17AWG 3C H05RN-F××& 3 1.0mm
2
300 20±
ψ×4.5 4PL
SOOW 17AWG 2C H07RN-F××& 2 1.0mm
2
SJOW 17AWG 2C H05RN-F××& 2 1.0mm
2
300 20±
: Max. Case Temperature
tc
113.8
113.8
58
58
8.9
15
15
78
125
13.4
235.2
262
tc
tc
Io
ADJ.
43.8
FG (Green/Yellow)
AC/L(Brown)
AC/N(Blue)
300 20±
ψ×4.5 4PL
SOOW 17AWG 2C H07RN-F××& 2 1.0mm
2
300 20±
330 20±
: Max. Case Temperature
tc
8.9
15
15
78
125
13.4
235.2
262
43.8
Vo-(Blue)
Vo-(Blue)
Vo+(Brown)
Vo+(Brown)
DIM-(Black)
DIM+(Gray)
