FXLQ-MAVE / FXNQ-MAVE
3
2. 6SHFL¿FDWLRQV
2.1 FXLQ-MAVE
Model FXLQ20MAVE FXLQ25MAVE
Power supply 1 phase, 220-240/220 V, 50/60 Hz 1 phase, 220-240/220 V, 50/60 Hz
+1 +3 Cooling capacity
kcal/h 1,900 2,400
Btu/h 7,500 9,600
kW 2.2 2.8
+2 +3 Heating capacity
kcal/h 2,200 2,800
Btu/h 8,500 10,900
kW 2.5 3.2
Power input
Cooling
50 Hz kW 0.049 0.049
60 Hz kW 0.047 0.047
Heating
50 Hz kW 0.049 0.049
60 Hz kW 0.047 0.047
Casing / Colour Ivory white (5Y7.5/1) Ivory white (5Y7.5/1)
Dimensions: (H×W×D) mm 600×1,000×222 600×1,000×222
Coil (Cross
¿n coil)
Rows × Stages ×
Fin pitch
mm 3×14×1.5 3×14×1.5
Face area
m
2
0.159 0.159
Fan
Model D14B20 D14B20
Type Sirocco fan Sirocco fan
Motor output ×
Number of units
W 15×1 15×1
AirÀow rate (H/L)
m³/min 7/6 7/6
l/s 116/100 116/100
cfm 247/212 247/212
Drive Direct drive Direct drive
Temperature control
Microprocessor thermostat for
cooling and heating
Microprocessor thermostat for
cooling and heating
Sound absorbing thermal insulation material Glass ¿ber / Urethane foam Glass ¿ber / Urethane foam
Air ¿lter Resin net (with mould resistance) Resin net (with mould resistance)
Piping
connections
Liquid pipes mm
I6.4 (Flare connection) I6.4 (Flare connection)
Gas pipes mm
I12.7 (Flare connection) I12.7 (Flare connection)
Drain pipe mm
I21 O.D (Vinyl chloride) I21 O.D (Vinyl chloride)
Mass kg 25 25
+4 Sound
pressure level
(H/L)
220 V, 50/60 Hz dB(A) 35/32 35/32
240 V, 50 Hz dB(A) 37/34 37/34
Safety devices Fuse, Thermal protector for fan motor Fuse, Thermal protector for fan motor
Refrigerant control Electronic expansion valve Electronic expansion valve
Standard accessories
Operation manual, Installation manual,
Insulation for ¿tting, Drain hose, Clamps,
Screws, Washers, Level adjustment screw
Operation manual, Installation manual,
Insulation for ¿tting, Drain hose, Clamps,
Screws, Washers, Level adjustment screw
Drawing No.
Speci¿cation C: 3D038816A C: 3D038816A
Sound level C: 4D034528A C: 4D034528A
Notes:
+1. Indoor temp.: 27°CDB, 19°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5 m, level difference: 0 m.
+2. Indoor temp.: 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5 m, level difference: 0 m.
+3. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
+4. Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m. During
actual operation, these values are normally somewhat higher as a result of ambient conditions.
Conversion formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
l/s=m³/min×1000/60
VRV INDOOR UNITS
