3 English
HOW TO CLEAN AIR OUTLET AND OUTSIDE PAN-
ELS
• Clean with soft cloth
• When it is difficult to remove stains, use water or neutral
detergent.
• When the flap is extremely contaminated, remove it as
below and clean or exchange it.
(Flap for exchange is optional)
NOTES
• Do not use gasoline, benzene, thinner, polishing powder,
liquid insecticide. It may cause discoloring or warping.
• Do not let the indoor unit get wet. It may cause an electric
shock or a fire.
• Do not scrub firmly when washing the blade with water.
The surface sealing may peel off.
• Do not use water or air of 50°C or higher for cleaning air fil-
ters and outside panels.
HOW TO CLEAN THE SUCTION GRILLE
1. Open the suction grille.
Push it downward slowly while pressing the buttons pro-
vided on two spots. (Follow the same procedure for clos-
ing.)
2. Detach the suction grille.
Open the suction grille 45 degrees and lift it upward.
3. Detach the air filter.
Refer to “HOW TO CLEAN THE AIR FILTER”.
4. Clean the suction grille.
Wash with a soft bristle brush and
neutral detergent or water, and dry
thoroughly.
• When very grimy
Directly apply the type of detergent
used for cleaning ventilation fans or ovens, wait 10 min-
utes, and then rinse with water.
NOTE
• Do not wash the air conditioner with hot water of more than
50°C, as doing so may result in discoloration and/or defor-
mation.
5. Reattach the air filter.
Refer to “HOW TO CLEAN THE AIR FILTER”.
6. Reattach the suction grille.
Refer to item No. 2.
7. Close the suction grille.
Refer to item No. 1.
01_EN_3PA60995-7X.fm Page 3 Wednesday, February 28, 2007 3:54 PM
