( for DA-Type only)

110

HVGC-1000 series is a 1000W LED AC/DC driver featuring the constant power mode with wide output

voltage range. HVGC-1000 operates from 180~528VAC and offers models with different rated current

ranging between 1320mA and 7000mA. Thanks to the high efficiency up to 96%, with the fanless design,

all models are able to operate for -40 ~+90 case temperature under free air convection. The design of

℃℃

metal housing and P67 ingress protection level allows this series to fit both indoor and outdoor I

applications, such as horticulture lighting and stadium light HVGC-1000 is equipped with various

function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED

lighting system.

1000W Constant Power Mode LED Driver

HVGC-1000 series

■ Description



arbor lightingH

LED high-bay lighting

Parking lot lighting

LED fishing lamp

Horticulture lighting

Stadium lighting

Type HL for use in Class , Division 2 Ⅰ

hazardous (Classified) location.

■ Features

■ Applications



Wide input range 180 ~ 528VAC

Constant power mode output

Metal housing with Class designⅠ

Surge protection with 8KV/4KV

Built-in active PFC function

IP67 design for indoor or outdoor installations

Dimming options: 3 in 1 dimming (dim-to-off);

Smart timer dimming and DALI 2.0

Auxiliary DC output 12v/500mA

Typical lifetime>50000 hours

5 years warranty

IP67

Type HL

■ Model Encoding

MAB

HVGC - 1000

Rated output current(L: 2800/ M: 4200/ H: 5600mA)

Rated wattage

Series name

Function options(AB/D2/Dx/DA2)

Built-in Smart timer dimming function by user request.IP67

By request

File Name:HVGC-1000-SPEC 2019-05-31

Type

FunctionIP Level

IP67

Built-in Smart timer dimming and programmable function.

Standard constant power output with 3 in 1 dimming function (0~10Vdc,

10V PWM signal and resistance) and built-in potentiometer.

DALI 2.0 control technology.

IP67

Note

In Stock

By request

A : Auxiliary DC output(12V@500mA)

: None
