100W Constant Current Mode LED Driver

HVGC-100 series

■ Description

HVGC-100 series is a 100W LED AC/DC LED drive featuring the constant current mode and high voltage

output. HVGC-100 operates from 180 528VAC and offers models with different rated current, 350mA~

and 700mA, respectively. Thanks to the high efficiency up to 91%, with the fanless design, the entire

series is able to operate for -40 ~ +90 case temperature under free air convection. The design of metal℃℃

housing and P67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications.I

HVGC-100 is equipped with various function options, such as dimming methodologies, so as to provide

the optimal design flexibility for LED lighting system.

LED street lighting

LED high-bay lighting

Parking space lighting

LED fishing lamp

■ Features ■ Applications



Wide input range 180 ~ 528VAC

Constant Current mode output

Metal housing with Class designⅠ

Built-in active PFC function

IP67 / IP65 design for indoor or outdoor installations

Function options: output adjustable via potentiometer;

3 in 1 dimming (dim-to-off) ; Timer dimming

Typical lifetime>50000 hours

5 years warranty

File Name:HVGC-100-SPEC 2018-09-30

Type

IP Level

IP65

IP67

Io adjustable through built-in potentiometer.

3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)

Function Note

In Stock

■ Model Encoding

- 700HVGC - 100

Rated output current(350/700mA)

Rated wattage

Series name

Function options

110

IP65 IP67

Bauar

Sicherheit

egel gema

t gepruft

www.

ID 2000000000

tuv.com

wac g

Timer dimming function, contact MEAN WELL for details(safety pending).

D IP67 By request

AB IP65

3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)

Io adjustable through built-in potentiometer &

In Stock
