100W Constant Current Mode LED Driver
HVGC-100 series
File Name:HVGC-100-SPEC 2018-09-30
OUTPUT LOAD vs TEMPERATURE(Note.9)
Tcase ( )℃
LOAD (%)
(HORIZONTAL)
-40-250 204555657590
20
40
60
80
100
PF
LOAD
STATIC CHARACTERISTIC
TOTAL HARMONIC DISTORTION (THD)
POWER FACTOR (PF) CHARACTERISTIC
EFFICIENCY vs LOAD
HVGC-100 series possess superior working efficiency that up to 91% can
be reached in field applications.
※ 700mA Model, Tcase at 80℃
※ 700mA Model, Tcase at 80℃
LOAD
※ Tcase at 80℃
THD(%)
LOAD
LOAD (%)
(100W)
LOAD (%)
-40 -25 -10 0 15 30 50 60 70
20
40
60
80
100
(HORIZONTAL)
INPUT VOLTAGE (V) 60Hz
180 347 480 528
100
90
80
70
60
50
40
200 440
AMBIENT TEMPERATURE,Ta ( )℃
※ De-rating is needed under low input voltage.
EFFICIENCY(%)
