OUTDOOR UNIT SEQUENCING TECHNOLOGY
DOUBLE BACKUP OPERATION FUNCTIONS RESPONDING RESILIENTLY TO
VARIOUS UNEXPECTED SITUATIONS
Automatic sequencing operation
During start-up, the Daikin VRV IV unit sequencing operation will be automatically enabled to
ensure balanced operation of each outdoor unit to improve longevity of equipment and stable operation.
Stage 1 Stage 2 Stage 3
Priority: Priority: Priority:
Automatic
sequencing
Automatic
sequencing
Automatic
sequencing
Automatic
sequencing
Daikin
VRV IV
system boasts double backup operation functions, which can secure the use of air
conditioners in this area to the greatest extent by emergently enabling double backup operation functions
even if failure occurs in a set of airconditioning equipment.
In the event of a failure, emergency operation can be conveniently enabled to allow the remaining system
to operate in a limited fashion.
Double backup operation functions
Unit backup operation function
If malfunction occurs in an outdoor unit...
Emergency operation can be conveniently set and enabled
by the remote controller for indoor unit (for systems
composed of two or more outdoor
units).
If malfunction occurs in a compressor...
Emergency operation can be easily set and
enabled by the outdoor unit (for a single outdoor
unit system RX(Y)Q14-20TRY6 models).
Compressor backup operation function
13
