![Daikin FXFQ32LUV1 [9/84] Installation space 0 1](/img/pdf.png)
Daikin FXFQ32LUV1 [9/84] Installation space 0 1
![Daikin FXVQ200MY1 [9/84] Installation space 0 1](/views2/1699335/page9/bg9.png)
Higher Coefficient of Performance (COP)
*Cooling operation conditions: Indoor temp. of
27ºCDB, 19ºCWB, and outdoor temp. of 35ºCDB.
0
3
3.5
4
4.5
6 HP
8 HP
4.30
4.41
Cooling
Operation
COP
Compact & lightweight design
Highly-integrated VRV IV
system offers compact
outdoor units to achieve
maximum utilisation of the
installation space.
Installation
Space
0.71 m
2
Product
Weight
195 kg
12 HP
12 HP
765
mm
930 mm
Improves heat exchanger
efficency, helps reduced
operation sound.
Lower operation sound
Peak in outdoor temperaturePeak in outdoor temperaturePeak in outdoor temperature
Enable night mode Enable night mode Enable night mode
Outdoor PCB automatically memorises the time when
the peak outdoor temperature appears. It enables
quiet operation mode after 8 h
*1
, and returns to
normal mode after it keeps this on for 9 h
*2
.
*1 8 h is the initial setting with 6 h or 10 h also available.
*2 9 h is the initial setting with 8 h or 10 h also available.
Notes: · This function is available in setting at site.
· The operating sound in quiet operation mode is the actual value
measured by our company.
· The relationship of outdoor temperature (load) and time shown
above is just an example.
Streamlined air grille
It promotes the discharge of
swirling airflow, further
reducing the
pressure loss.
Streamlined scroll fan
The sharp edge of each fan blade
has a certain curvature, reducing
both the vibration and the pressure
loss.
Streamlined
scroll fan
Illustrated
fan
Operating
sound (dB)
Load
(%)
Capacity
(%)
Night mode
min.
40 dB(A)
8 hrs
8:00
50
60
50
100
0
40
57
12:00 16:00 20:00 0:00
4:00
8:00
9 hrs
VRV IV VRV IV
6 HP 8 HP 10 HP 12 HP
55 56 57 59
Sound level(dB(A))
Quiet night-time operation function
Without increasing operation sound, advanced
analytic technologies are utilised to optimise fan
design, increase airflow rate and external static
pressure.
Large airflow, high static pressure and
quiet technology
ENERGY SAVING
EASE OF INSTALLATION
COMFORT
7
