MEAN WELL HVGC-150-1400A Datasheet онлайн
150W Constant Current Mode LED Driver
HVGC-150 series
■ Description
HVGC-150 series is a 150W LED AC/DC LED power supply featuring the constant current mode and high
voltage output. HVGC-150 operates from 180 528VAC and offers models with different rated current ranging~
between 350mA and 1400mA. Thanks to the high efficiency up to 91%, with the fanless design, the entire
series is able to operate for -40 ~ +80 case temperature under free air convection. The design of metal℃℃
housing and P67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications.I
HVGC-150 is equipped with various function options, such as dimming methodologies, so as to provide
the optimal design flexibility for LED lighting system.
LED street lighting
LED high-bay lighting
Parking space lighting
LED fishing lamp
Type HL for use in Class , Division 2Ⅰ
hazardous (Classified) location.
■ Features ■ Applications
Wide input range 180 ~ 528VAC
Constant Current mode output
Metal housing with Class designⅠ
Built-in active PFC function
IP67 / IP65 design for indoor or outdoor installations
Function options: output adjustable via potentiometer;
3 in 1 dimming (dim-to-off) ; Timer dimming
Typical lifetime>50000 hours
5 years warranty
File Name:HVGC-150-SPEC 2018-09-30
Type
A
B
IP Level
IP65
IP67
Io adjustable through built-in potentiometer.
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
Function Note
In Stock
In Stock
■ Model Encoding
- 1750HVGC - 150
A
Rated output current(350/500/700/1050/1400mA)
Rated wattage
Series name
Function options
MM
110
IP65 IP67
Bauar
Sicherheit
egel gema
t gepruft
od
be
www.
ID 2000000000
tuv.com
wac g
os
Type HL
Timer dimming function, contact MEAN WELL for details(safety pending).
D IP67 By request
AB IP65
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
Io adjustable through built-in potentiometer &
In Stock
