Case No. 994 Unit:mm
※ B-Type
※ A-Type
150W Constant Current Mode LED Driver
HVGC-150 series
File Name:HVGC-150-SPEC 2018-09-30
MECHANICAL SPECIFICATION
245
221
12
9.6
+V(Red)
-V(Black)
300 20±
FG (Green/Yellow)
FG (Green/Yellow)
AC/L(Brown)
AC/L(Brown)
AC/N(Blue)
AC/N(Blue)
9.4 9.4
34.2
68
ψ×4.2 4PL
300 20±
106.9
106.9
34
34
245
221
12
9.6
+V(Red)
-V(Black)
DIM-(White)
DIM+(Blue)
STW 18AWG 3C×
300 20±
9.4 9.4
34.2
68
ψ×4.2 4PL
300 20±
UL2517 18AWG 2C×
STW 18AWG 2C×
Io
ADJ.
STW 18AWG 2C×
STW 18AWG 3C×
38.8
38.8
: Max. Case Temperature
: Max. Case Temperature
tc
tc
tc
tc
