Griven ARCO 650 [9/12] Packaging and transport

2.1 Packaging

Check carefully the content of the box and, in case of damage, contact your forwarder immediately. The fol-

lowing items are included in the box of this unit:

n° 1 Arco 650/1000 PC or Fresnel unit

n° 1 owner’s manual

2.2 Transport

The carton box has not been designed to be used more than once, therefore, it is recommended to use one of

our flight cases to transport the unit.

3.1 Fixing

The unit can be used both rested on floor and fixed onto a structure. Use the hole Ø12.5 (1/2”) in the bracket to

fix the unit.

To fix the unit onto a supporting structure or truss, it is suggested to use hooks type “Aliscaff”. The hooks are to be

fitted to the unit through the holes in the bracket.

3.2 Safety chain

If hooking Arco 650/1000 up to a truss or a supporting structure, a safety chain must be installed. This safety chain

must be able to bear at least 10 times the weight of the unit, as prescribed by in force rules.

3.3 Adjusting light beam direction

Ensure that Arco 650/1000 is always used with the lamp base downwards. If the position of the spotlight is re-

versed, the lamp will overheat and drastically reduce lamp life.

3.4 Connection to mains power

The unit can operate with voltage of 230Vac and with frequency of 50 and 60Hz.

Warning!

• Before connecting the unit, verify that power supplies features are compatible with the unit features.

• The unit must never be installed if not grounded electrically.

• It is suggested to use a magnetothermic switch along the power supply line, as prescribed by in force rules.

• Wiring and connection actions are to be performed by a qualified staff.

Warning!

Check that the fixing hook is not damaged

and is able to bear at least 10 times the weight of the unit.

Check that the structure can bear at least 10 times the weight of

the unit, the hooks, the additional equipments, etc.

If the unit must be raised, block out the access under the working area.

Operate in safe conditions on a stable platform.

3.0 Installation

Warning!

• Griven S.r.l. liability will cease upon consignment of goods to the forwarder: claims for damage due to trans-

port must be addressed directly to the forwarder.

• Griven S.r.l. will accept claims for broken or missing goods only within seven days of receipt of the goods.

• Returns of equipment will not be accepted without prior authorization granted by Griven S.r.l. and if not duly ac-

companied by relevant shipping documents.

2.0 Packaging and transport

English 9
