File Name:LCM-60BLE-SPEC 2019-08-13

60W Multiple-Stage Constant Current Mode LED Driver

LCM-60BLE

Push Button

AC/N

AC/L

DIMMING OPERATION

※Casambi Bluetooth control

‧To be used through APP available on Apple Store and Play Store for iOS and Android.

PUSH

AC/N

AC/L

LCM-60BLE

AC mains

※Freely assignable (push) input

‧The LCM BLE series also has one freely assignable AC mains (push) input. As with a CASAMBI sensor module, control pulses can be defined here

(e.g. “controls a luminaire”; “controls an element”; “controls a group”; “controls scenes”; “controls all luminaires”; “change scenes”). See the reference

connection figure in the above.

■APP SOFTWARE OVER TEMPERATURE PROTECTION

The real time Bluetooth IC temperature is shown in the APP. In case it reaches above 75 ºC (equivalent to Tc 90ºC), the driver will be turn off to provide a protection.

In case the units is cooled down, it can be manually turn ON and back to normal operation again.

NOTE: 1.This software temperature protection is an extra independent function from driver its own hardware over temperature protection(when it is enabled, it needs

re-AC power on to recover) and temperature compensation operation function described in the following section.

2.In general the software temperature protection is triggered before the hardware one when in over temperature.
