File Name:LCM-60BLE-SPEC 2019-08-13
60W Multiple-Stage Constant Current Mode LED Driver
MECHANICAL SPECIFICATION
Case No.LCM-60A Unit:mm
TB3
TB1
CN100
CN101
tc
‧ : Max. Case Temperature
tc
TB5
2
3
1
1
2
※SYN. Connector( ):JST B2B-XH or equivalentCN101/CN100
Pin No. Assignment Mating Housing
JST XHP
or equivalent
Terminal
JST SXH-001T-P0.6
or equivalent
1,3
2,4
+
-
※Terminal Pin No. Assignment( ) TB5
※Terminal Pin No. Assignment( ) TB1
Pin No.
Pin No.
1
1
2
2
3
Assignment
Assignment
+V
AC/L
-V
AC/N
PUSH
※Terminal Pin No. Assignment( ) TB3
Pin No. Pin No.
1
2
3
4
Assignment Assignment
+FAN(optional) +NTC
-NTC-FAN(optional)
1
3
2
4
Bottom View
6.75
6.75
68
81.5
6.75
110
123.5
6.75
39.3 65.5
7.8 7.8
SYN.
1
2
3
4
ON
654321
4
23
40
15
◎ Pin1(+FAN) / Pin2(-FAN) is the Auxiliary DC output for the optional model; it can be used to drive fan.
2-ψ
4
.
2
Installation Manual
2-ψ4
Please refer to : http://www.meanwell.com/manual.html
LCM-60BLE
