MEAN WELL LPC-100-350 Datasheet онлайн
Constant current design
Universal AC input/full rauge
Withstand 300VAC surge input for 5 seconds
High efficiency up to 90%
Protections: Short circuit / Over voltage
Cooling by free air convection
Fully encapsulated with IP67 level (Note.6)
Fully isolated plastic case
Class power unit, no FGⅡ
100% full load burn in test-
Low cost, high reliability
2 years warranty (Note.4)
100W Single Output LED Power Supply
LPC-100 series
File Name:LPC-100-SPEC 2017-11-03
■ Description
■ Features ■ Applications
■ Model Encoding
- 700
LPC
-
100
Output current
Output wattage
Series name
Suitable for LED related
fixture or appliance
(such as LED Decoration
or Advertisement devices)
LPC-100 series is one 100W single output AC/DC LED switching power supply. It features the
constant current design, providing various models with the output current ranging from 350mA
through 2100mA the LED lighting applications employ the most frequently.
LPC-100 operates for the range 90~264VAC so it can perfectly work for most of the countries in
the world. The whole series is based on class II (without FG pin) design, housed with a 94V-0
flame retardant plastic case. With the working efficiency up to 90%, LPC-100 can work at the
ambient temperature between -25 ~+50 under air convection.℃℃
IP67
