MEAN WELL LPC-100-350 [3/3] V red v black ul 1015 18awg ul 1015 18awg
![MEAN WELL LPC-100-350 [3/3] V red v black ul 1015 18awg ul 1015 18awg](/views2/1701473/page3/bg3.png)
Mechanical Specification
File Name:LPC-100-SPEC 2017-11-03
PWM
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
CONTROL
&
Block Diagram
DETECTION
CIRCUIT
O.V.P.
AC/N(Blue)
AC/L(Brown)
LOAD (%)
20
40
60
80
100
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 264
100
90
80
70
60
50
40
LOAD (%)
Derating Curve
LOAD (%)
Derating Curve Static Characteristics
AMBIENT TEMPERATURE ( )℃
LOAD (%)
175
LOAD (%)
(HORIZONTAL)
-15 0 15 30
04050-25 60 70
Case No. LPC-100 Unit:mm
+V(Red)
-V(Black)
UL 1015 18AWG
UL 1015 18AWG
Recommend Mounting Direction
100W Single Output LED Power Supply
LPC-100 series
190
52
3.5
3.5
3.5
3.5
300±10
300±10
37
2.5
Tcase
17
96
※ T case: Max. Case Temperature.
fosc : 67KHz
