Si34-803 Field Setting
Test Operation 205
(13) Setting of Normal Air Flow
Make the following setting according to the ceiling height. The setting position No. is set to “01”
at the factory.
In the Case of FXAQ
In the Case of FXHQ
In the Case of FXFQ25~80 (All round outlet)
In the Case of FXFQ100~125 (All round outlet)
In the Case of FXFQ25~80 (*
2
4-Way, 3-Way, 2-Way Outlets)
In the Case of FXFQ100~125 (*
2
4-Way, 3-Way, 2-Way Outlets)
*1 “Mode No.” setting is done in a batch for the group. To make or confirm settings for an
individual unit, set the internal mode number in parentheses.
*2 The figure of the ceiling height is for the all round outlet. For the settings for four-direction
(part of corner closed off), three-direction and two-direction outlets, see the installation
manual and technical guide supplied with the separately sold closure material kit.
Mode No.
Setting Switch
No.
Setting Position
No.
Setting
13(23) 0
01 Wall-mounted type: Standard
02 Wall-mounted type: Slight increase
03 Wall-mounted type: Normal increase
Mode No. First code No.
Second code
No.
Ceiling height (m)
13(23) 0
01 2.7 or less
02 2.7-3.5
Mode
No.
First
code
No.
Second
code
No.
Setting Ceiling height (m)
13 (23) 0
01
Standard • All
round outlet
≤2.7
02 High Ceiling (1) 2.7-3
03 Higher Ceiling (2) 3-3.5
Mode
No.
First
code
No.
Second
code
No.
Setting Ceiling height (m)
13 (23) 0
01
Standard • All
round outlet
≤3.2
02 High Ceiling (1) 3.2-3.6
03 Higher Ceiling (2) 3.6-4.2
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 3.1 m Lower than 3.0 m Lower than 3.5 m
02 High Ceiling (H) Lower than 3.4 m Lower than 3.3 m Lower than 3.8 m
03 Higher Ceiling (S) Lower than 4.0 m Lower than 3.5 m —
Mode
No.
First
code
No.
Second
code
No.
Setting
Ceiling height
4-way Outlets 3-way Outlets 2-way Outlets
13 (23) 0
01 Standard (N) Lower than 3.4 m Lower than 3.6 m Lower than 4.2 m
02 High Ceiling (H) Lower than 3.9 m Lower than 4.0 m Lower than 4.2 m
03 Higher Ceiling (S) Lower than 4.5 m Lower than 4.2 m —
