Specifications
Model
ZKD1702 ZKD1703
LCD Type
Type 17" TFT LCD Panel 17" AUO TFT LCD Panel
Dimension 384*55*315mm (L*W*H)
Display Area 341×273(mm)
Max Resolution 1280×1024 @ 60Hz
Color 16.7 million
Brightness 250cd/m2
Response Time 5ms
Visual Angle
(Typ.at CR > 10)
Horizontal (left/right): 85°/85°
Vertical (upper/lower): V80°/80°
Contrast Ratio 1000:1
Video Input Format VGA
MTBF 50,000 hours
LED Backlight Lifespan 50,000 hours
Touch Panel
Type
ZKD1702R: 5 wires resistive
touch (Standard)
ZKD1702C: capacitive touch
(Optional)
ZKD1703R: 5 wires resistive touch from Taiwan
Higgstec (anti-high temperature)(Standard)
ZKD1507C: capacitive touch from Taiwan Higgstec
(anti-high temperature) (Optional)
Interface USB
Response Time USB: 10 ms
Power Supply
Type External power adapter
Power Adapter 12V 3A Power adapter 12V 3A Power adapter from Taiwan
Input Voltage 100-240 VAC, 50-60 Hz
Output Voltage 12 volts at 4 amps max
Power Consumption 12W(Max)
Work Environment
Operating Temp. 0°C~50°C
Storage Temp. -20°C~60°C
Operating Humidity 5%~90%
Storage Humidity 5%~90%
Appearance
Installation Mode
1)VESA 75 mm
2) Using a horizontal or vertical mounting support
OSD Control
Button AUTO, +, POWER, MENU
Function
Brightness, Contrast, Auto correction, Phase, Clock, Row and column position,
Language, Function setting, Reset
Other
Accessory Power cable; Power adapter; USB cable; VGA cable
Warranty Period 1 year
ZKTECO CO.,LTD. www.zkteco.com E-mail: sales@zkteco.com
© Copyright 2018 ZKTECO CO., LTD. All rights reserved.
V1. 0 2018. 06. 29
