MEAN WELL ODLC-45-350 Datasheet онлайн

Constant Current mode output

Flicker free design

Plastic housing with class II design

Built-in active PFC function

No load power consumption<0.5W(Blank-Type),

Standby power consumption<0.5W(DA-Type)

IP67 rating for indoor or outdoor installations

Function options: 2 in 1 dimming (dim-to-off);

Auxiliary DC output; DALI

3 years warranty

■ Model Encoding

■ Description

■ Features ■ Applications



LED panel lighting

LED flood lighting

Indoor LED lighting

Rated output current(350/500/700/1050/1400mA)

Rated wattage

Series name

350

ODLC

File Name:ODLC-45-SPEC 2018-09-29

ODLC-45 series is a 45W LED AC/DC driver featuring the constant current mode output with

flicker free design.ODLC-45 operates from 90~295VAC and offers models with different rated

current ranging between 350mA and 1400mA. Thanks to the efficiency up to 86%, with the

fanless design, the entire series is able to operate for -20 ~+85 case temperature under free℃℃

convection. The design of plastic housing and IP67 ingress protection level allows this series

dimming methodologies, so as to provide the optimal design flexibility for lighting system.

M M

SELV

Function options

Type

Blank

Function Note

In Stock

45W Constant Current Mode LED Driver

ODLC-45 series

2 in 1 dimming (0~10VDC and 10V PWM)

Type HL

to fit indoor wet applications. ODLC-45 is equipped with various function options, such as

DALI control technology

(for DA-Type only)

A:Auxiliary DC output(12V@50mA)

:None

{

Note: The DALI control model(DA Type) only for ODLC-45 Non Auxiliary DC output models.

IS 15885(Part 2/Sec13)

R-41027766

THOMAS SAMUEL

( for ODLC-45-700,1050,700DA,1050DAonly)

IP67

(for enclosure design only)
