12W Single Output LED Power Supply

PLM-12 series

230VAC only or Full range (up to 295VAC)

models available

Built-in active PFC function

Constant current design

Protections:Short circuit

Cooling by free air convection

Fully isolated plastic case

Class power unit, no FGⅡ

Class 2 power unit (Blank type only)

No load power consumption <0.5W

High reliability,low cost

2 years warranty

SELV

110

IP30

■ Features ■ Applications

(for Blank type only)

Indoor LED lighting

LED office lighting

LED commercial lighting

LED decorative lighting

■ Model Encoding

■ Description

PLM-12 is a 12W economical AC/DC LED power supply series. Incorporating a built-in active PFC

design, PLM-12 provides a high Power Factor value greater than 0.9. In addition, with the low no load

power consumption below 0.5W, and the setup time less than 500ms, PLM-12 is complied with the ErP

regulation required by European Union for lighting fixtures.

PLM-12 is a class (without FG pin) power unit housed with the UL 94V-0 rated flame retardantⅡ

plastic case. The /O terminals are designed with screw-less clamp style terminal block that greatlyI

simplifies the wiring installation. Two types of models with different input voltage range are offered:

PLM-12 series, which operates from 110~295VAC, and PLM-12E series, which operates from

180~295VAC.These two series are both constant current output design, supplying models with the

Output current

Output wattage

Series name

- 350PLM - 12

current of 350mA, 500mA, 700mA and 1050mA, respectively.

Blank: AC input range 110~295VAC

{

E:AC input range 180~295VAC

File Name:PLM-12-SPEC 2018-01-10

(for E type only)
