MEAN WELL PLP-30-48 [2/3] Plp 30
![MEAN WELL PLP-30-48 [2/3] Plp 30](/views2/1704873/page2/bg2.png)
Mechanical Specification
File Name:PLP-30-SPEC 2014-03-13
Unit:mm
Derating Curve Static Characteristics
AMBIENT TEMPERATURE (℃)
LOAD (%)
-30 -25 -5 0 20 40 50 60 70
20
40
60
80
100
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 264
100
90
80
70
60
50
40
LOAD (%)
(HORIZONTAL)
fosc : 90KHz(115VAC)
120KHz(230VAC)
Block Diagram
50
AC Input Connector (CN1) : JST B3P-VH or equivalent DC Output Connector (CN2) : JST B2P-VH or equivalent
Pin No. Pin No.
1 1
3
22
Assignment Assignment
AC/L +V
AC/N
-VNo Pin
Mating Housing Mating Housing
JST VHR
JST VHR
or equivalent
or equivalent
Terminal Terminal
JST SVH-21T-P1.1
JST SVH-21T-P1.1
or equivalent
or equivalent
T1A /250V
AC FUSE
CN1
1
2
3
CN2
HS2
HS1
SVR1
1
2
3.175
95.25
101.6
FS1
26.6
3max.
3.175
.
.
44.45
50.8
4-ψ3.2
HS1,HS2 can not be shorted
: Grounding required
DETECTION
PWM & PFC
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
30W Single Output LED Power Supply
PLP-30 series
