SPECIFICATION

MODEL PLP-60-12 PLP-60-24 PLP-60-48

DC VOLTAGE

RATED CURRENT

CURRENT RANGE

RATED POWER

OUTPUT

CURRENT ADJ. RANGE

LINE REGULATION

LOAD REGULATION

SETUP TIME

VOLTAGE RANGE Note.4

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INPUT

INRUSH CURRENT (max.)

LEAKAGE CURRENT

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

OVER CURRENT

Note.5

SHORT CIRCUIT

OVER VOLTAGE

12V 24V 48V

18 ~ 24V 36 ~ 48V

0 ~ 5A

2.5A

0 ~ 2.5A

1.3A

0 ~ 1.3A

60W 60W 62.4W

4.5Vp-p 4.5Vp-p

1.875 ~ 2.5A

4.8Vp-p

0.975 ~ 1.3A

±10%

±3.0%

±5.0%

500ms / 230VAC 1200ms / 115VAC at full load

47 ~ 63Hz

PF 0.9 at 75 ~ 100% load, 115VAC / 230VAC≧

84% 88% 89%

15 ~ 18V 28 ~ 35V 57 ~ 63V

0.8A/115VAC 0.4A/230VAC

<0.75mA / 240VAC

Protection type : Constant current limiting, recovers automatically after fault condition is removed

-30 ~ +70 (Refer to "Derating Curve")℃

20 ~ 95% RH non-condensing

-40 ~ +80 , 10 ~ 95% RH℃

± ℃ ℃0.03%/ (0 ~ 50 )

10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes

583.3K hrs min. MIL-HDBK-217F (25 )℃

101.6*50.8*29.6mm (L*W*H)

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

4. Derating may be needed under low input voltage. Please check the static characteristics for more details.

5. lease refer to "DRIVING METHODS OF LED MODULE".P

6. Heat sink HS1,HS2 can not be shorted.

7. Heat sink HS1 must have safety isolation distance with system case.

8. The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the

complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.

9. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.

10. To fulfill requirements of the latest ErP regulation for lighting fixtures, this LED power supply can only be used behind a switch without permanently

connected to the mains.

0.16Kg; 96pcs/16.4Kg/0.89CUFT

‧

Universal AC input / Full range

‧

Protections: Short circuit / Over current / Over voltage

‧

Built-in active PFC function

‧

Cooling by free air convection

‧

Class 2 power unit

‧

Output current level adjustable

‧

100% full load burn-in test

‧

High reliability

‧

Suitable for built-in applications of LED lighting

‧

2 years warranty

■

Features :

RIPPLE & NOISE (max.)

Note.2

VOLTAGE TOLERANCE

Note.3

ENVIRONMENT

SAFETY &

EMC

PROTECTION

SAFETY STANDARDS

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃

Compliance to EN55015, EN61000-3-2 Class C( 75% load); EN61000-3-3≧

Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024,EN61547, light industry level, criteria A

3.75 ~ 5A

100 ~ 110%

Protection type : Shut down o/p voltage, re-power on to recover

Hiccup mode, recovers automatically after fault condition is removed

60W Single Output LED Power Supply

PLP-60

seri e s

File Name:PLP-60-SPEC 2015-02-12

9 ~ 12V

EMC IMMUNITY

EMC EMISSION

UL8750, TUV EN61347-1, EN61347-2-13, CSA C22.2 No. 250.0-08(except for 48V) approved ; design refer to UL60950-1

COLD START 35A(t =55 s measured at 50% I ) at 230VAC

width peak

CONSTANT CURRENT REGION

Note.5

( for 48V only) ( except for 48V )

90 ~ 264VAC 127 ~ 370VDC
