MEAN WELL PLP-45-24 [2/3] Block diagram

MEAN WELL PLP-45-24 [2/3] Block diagram
Mechanical Specification
File Name:PLP-45-SPEC 2014-03-13
Unit:mm
Derating Curve Static Characteristics
AMBIENT TEMPERATURE (℃)
LOAD (%)
-30 -25 -5 0 20 40 50 60 70
20
40
60
80
100
INPUT VOLTAGE (V) 60Hz
90 100 125 135 145 155 165 175 180 200 230 264
100
90
80
70
60
50
40
LOAD (%)
(HORIZONTAL)
fosc : 90KHz(115VAC)
120KHz(230VAC)
Block Diagram
DETECTION
PWM & PFC
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
50
AC Input Connector (CN1) : JST B3P-VH or equivalent
DC Output Connector (CN2) : JST B2P-VH or equivalent
Pin No.
Pin No.1
1
3 2
2
Assignment
AssignmentAC/L
+V
AC/N -V
No Pin
Mating Housing
Mating Housing
JST VHR
JST VHR
or equivalent
or equivalent
Terminal
Terminal
JST SVH-21T-P1.1
JST SVH-21T-P1.1
or equivalent
or equivalent
: Grounding required
CN2
CN1
FS1
1
2
1
2
3
3.175
3.175
95.25
101.6
.
.
HS2HS1
SVR1
PLP-45 series
45W Single Output LED Power Supply
29.6
3max.
4-ψ3
.2
44.45
50.8



