Refrigerant Flow for Each Operation Mode Si34-803
94 Refirgerant Circuit
Heating Oil Return & Defrost Operation
Thermostat "ON"
EV:416pls EV:256pls EV:416pls
Fan OFFFan OFF Fan OFF
Indoor unit
Thermostat "OFF"
Indoor unitIndoor unit
Indoor unit operation
" OFF " " ON "" ON "
"High temperature, high pressure gas"
"High temperature, high pressure liquid"
"Low temperature, low pressure"
Electronic expansion valve
FilterFilter
Heat exchanger
Fan
Electronic expansion valve
FilterFilter
Heat exchanger
Fan
Electronic expansion valve
FilterFilter
Heat exchanger
Fan
