MEAN WELL PWM-120-12DA [6/7] Pwm 120ble

120W PWM Output Casambi Bluetooth LED Driver

Mechanical Specification

Case No. PWM-120 Unit:mm

Block Diagram

DETECTION

DIMMING

PWM & PFC

CIRCUIT

O.L.P.O.T.P.

EMI FILTER

RECTIFIERS

POWER

SWITCHING

FILTER

RECTIFIERS

-V

I/P

CONTROL

O.V.P.

O.L.P.

PFC

CIRCUIT

PFC fosc : 50~120KHz

PWM fosc : 60~130KHz

File Name:PWM-120BLE-SPEC 2019-11-06

AC/N(Blue)

AC/L(Brown)

37.5

191

300 20±

T case

31.5

95.5

‧ : Max. Case Temperature

+V(Red)

-V(Black)

50±3

SJOW 17AWG×2C

50±3

2-ψ 4.5

&H05RN-F 1.0mm

SJOW 17AWG×2C

&05RN-F 2×1.0mm

PWM-120BLE



 metal or

any material that stops RF signal





MCU


