MEAN WELL SLD-50-56 [4/6] Series

SLD-50 series

BLOCK DIAGRAM

50W linear LED Driver

※ This series is able to work in either Constant Current mode (a direct drive way) or

Constant Voltage mode (usually through additional DC/DC driver) to drive the LEDs.

DRIVING METHODS OF LED MODULE

Typical output current normalized by rated current (%)

In the constant current region, the highest voltage at the output of the driver

depends on the configuration of the end systems.

Should there be any compatibility issues, please contact MEAN WELL.

100

(min.)

Vo(%)

100

Io(%)

(B)

Constant

Current area

(C)

Hiccup

Protection

(A)

Constant

V areaoltage

DETECTION

PWM & PFC

CIRCUIT

O.L.P.O.T.P.

EMI FILTER

RECTIFIERS

POWER

SWITCHING

FILTER

RECTIFIERS

Vo+

Vo-

I/P

CONTROL

O.V.P.

O.L.P.

PFC

CIRCUIT

PFC fosc : 50~120KHz

PWM fosc : 60~130KHz

File Name:SLD-50-SPEC 2019-11-13

◎ SLD-50-12,24

◎ SLD-50-56

900mA, 56V

1400mA, 36V

1400mA , 30V

900mA, 30V

450mA, 56V

25V

30V

35V

40V

45V

50V

55V

60V

0mA 300mA 600mA 900mA 1200mA 1500mA

Recommend Performance Region
