MEAN WELL UHP-200A-4.2 [3/5] Uhp 200
![MEAN WELL UHP-200A-4.2 [3/5] Uhp 200](/views2/1705167/page3/bg3.png)
OUTPUT LOAD vs TEMPERATURE
AMBIENT TEMPERATURE,Ta ( )℃
LOAD (%)
(HORIZONTAL)
-30 -25 -10 0 15 30 50 60 70
20
40
60
80
100
STATIC CHARACTERISTIC
INPUT VOLTAGE (V) 60Hz
LOAD (%)
90 110 150 180 200 240 264
100
90
80
70
60
50
40
Block Diagram
PWM
CIRCUIT
DETECTION
O.L.P.
EMI
FILTER
APFC
POWER
SWITCH-
FILTER
&
SYNCHRONOUS
I/P
FG
ING
CONVERTER
O.V.P.
BRIDGE
RECTIFIERS
O.T.P.
CONTROLLER
RECTIFIERS
+V
-V
DC OK Function
PFC fosc : 65KHz
PWM fosc : 75~200KHz
100
File Name:UHP-200A-SPEC 2017-09-05
UHP-200A series
200W Single Output with PFC Function
