1.Operate with additional aluminum plate

aluminum plate(or the cabinet of the same size) on the bottom.The size of the suggested aluminum plate is shown

as below. And for optimizing thermal performance, the aluminum plate must have an even and smooth surface

In order to meet the“Derating Curve”and the “Static Characteristics” ,UHP-200A series must be installed onto an

Installation

2.For heat dissipation, at least 5cm installation distance around the PSU should be kept, shown as below:

UHP-200A series

200W Single Output with PFC Function

M3*4
