100W Constant Power Mode LED Driver

XBG-100 series

File Name:XBG-100-SPEC 2020-01-02

MECHANICAL SPECIFICATION

Case No.280 Unit:mm

※ A-Type(AC Cable with fixed cable)

※ AB-Type(AC Cable with fixed cable)

‧Ta: Ambient Temperature measured point

‧ : Max. Case Temperature.(case temperature measured point)

tc

ψ126.6

4- 6.0ψ

SJOW 17AWG*2C

+V(Red)

-V(Black)

200±20

5

34.6

39.6

56

300±20

AC/L(Brown)

AC/N(Blue)

PE (Green/Yellow)

SJOW 17AWGx3C

2

&H05RN-F 3x1.0mm

Ta

45°

150

113

113

tc

20

14.5

SJOW 17AWG*2C

+V(Red)

-V(Black)

200±20

5

34.6

39.6

56

350±20

DIM+(Blue)

DIM-(White)

UL2517 22AWG*2C

300±20

AC/L(Brown)

AC/N(Blue)

PE (Green/Yellow)

SJOW 17AWGx3C

2

&H05RN-F 3x1.0mm

Ta

45°

150

113

113

ψ126.6

4- 6.0ψ

tc

20

14.5
