![MEAN WELL XBG-100-AB [8/8] Xbg 100](/views2/1705199/page8/bg8.png)
100W Constant Power Mode LED Driver
XBG-100 series
File Name:XBG-100-SPEC 2020-01-02
INSTALLATION MANUAL
‧Ta: Ambient Temperature measured point
‧ : Max. Case Temperature.(case temperature measured point)
tc
Terminal Pin No. Assignment(CHOGORI 22003515-01)
Pin No.
1
2
3
Assignment
AC/L
PE
AC/N
Drawing
1
2
3
※ AB-C-Type(AC cable with connector)
※ A-C-Type(AC cable with connector)
AC input cable option
Item
1M
2M
3M
Order part NO.
1FF5XBG-160-IP1
1FF5XBG-160-IP3
1FF5XBG-160-IP2
1000 or 2000 or 3000 mm
CHOGORI 22003211-01
2
H05RN-F 3C*0.75mm
5
34.6
39.6
56
113
113
SJOW 17AWG*2C
+V(Red)
-V(Black)
200±20
Ta
45°
150
ψ126.6
4- 6.0ψ
M10*P1.5-18h
tc
20
14.5
5
34.6
39.6
56
113
113
SJOW 17AWG*2C
+V(Red)
-V(Black)
200±20
350±20
DIM+(Blue)
UL2517 22AWG*2C
DIM-(White)
Ta
45°
150
ψ126.6
4- 6.0ψ
M10*P1.5-18h
tc
20
14.5
