160W Constant Power Mode LED Driver

XBG-160 series

SPECIFICATION

MODEL

DEFAULT CURRENT

RATED POWER

FULL POWER CURRENT RANGE

OUTPUT

CURRENT ADJ. RANGE

VOLTAGE RANGE Note.2

FREQUENCY RANGE

POWER FACTOR (Typ.)

EFFICIENCY (Typ.)

AC CURRENT (Typ.)

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

SAFETY STANDARDS

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

VIBRATION

MTBF

DIMENSION

OTHERS

OVER VOLTAGE

OVER TEMPERATURE

1425~4100mA

47 ~ 63Hz

2.0A / 115VAC 0.8A / 230VAC 0.7A / 277VAC

<0.75mA / 277VAC

20 ~ 95% RH non-condensing

-40 ~ +80℃, 10 ~ 95% RH non-condensing

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

1100K hrs min. Telcordia SR-332(Bellcore) ; 280K hrs min. MIL-HDBK-217F (25℃)

ENVIRONMENT

SAFETY &

EMC

PROTECTION

SHORT CIRCUIT

93%

3300mA

159.9W

2850~4100mA

COLD START 50A(twidth=620 s measured at 50% Ipeak) at 230VAC; Per NEMA 410

TOTAL HARMONIC DISTORTION

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

CONSTANT CURRENT REGION

PACKING

1.25Kg; 8pcs/11.5Kg/0.93CUFT

NOTE

MAX. NO. of PSUs on 16A

CIRCUIT BREAKER

4 unit(circuit breaker of type B) / 7 units(circuit breaker of type C) at 230VAC

Hiccup mode, recovers automatically after fault condition is removed

(Please refer to "STATIC CHARACTERISTIC" section)

90 ~ 305VAC

34 ~ 56V

OPEN CIRCUIT VOLTAGE (max.)

60V

61 ~ 78V

Shut down output voltage, re-power on to recovery

TEMP. COEFFICIENT

±0.03%/℃ (0 ~ 60℃)

WORKING TEMP.

Tcase=-40 ~ +90℃(Please refer to "OUTPUT LOAD vs TEMPERATURE" section)

MAX. CASE TEMP.

Tcase=+90℃

PF 0.97 / 115VAC, PF 0.95 / 230VAC full load≧ ≧ , PF≧0.92 / 277VAC at

(Please refer to " " )Power Factor Characteristic section

THD< 10% (@ load≧60% at 115VAC/230VAC ,@load≧75% at 277VAC)

Please refer to “TOTAL HARMONIC DISTORTION (THD)” section

CURRENT RIPPLE 5.0% max. @rated current

CURRENT TOLERANCE ±5%

SET UP TIME Note.4 500ms/230VAC, 2000ms/115VAC

NO LOAD / STANDBY

POWER CONSUMPTION

No load power consumption<0.5W for A-Type

Standby power consumption<0.5W for AB-Type

UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384;

GB19510.1,GB19510.14; IP67 approved

LIFETIME Note.5 50000 hrs min.

φ151.5mm *60mm(D*H)

Shut down output voltage, recovers automatically after temperature goes down

 ℃









 ℃

 





  ℃ ℃







XBG-160- -

EMC IMMUNITY

EMC EMISSION

Parameter

Conducted

Radiated

Harmonic Current

Voltage Flicker

EN55024 , EN61204-3, EN61000-6-2

Parameter

ESD

Radiated

EFT/Burst

Surge

Conducted

Magnetic Field

Voltage Dips and Interruptions

Standard

EN61000-3-2

EN61000-3-3

Standard

EN61000-4-2

EN61000-4-3

EN61000-4-4

EN61000-4-5

EN61000-4-6

EN61000-4-8

EN61000-4-11

Test Level/Note

-----

Class C @load≥50%

-----

Test Level/Note

Level 3, 8KV air ; Level 2, 4KV contact

Level 3

4KV/Line-Line 6KV/Line-Earth

Level 3

Level 4

>95% dip 0.5 periods, 30% dip 25 periods,

>95% interruptions 250 periods

EN55015(CISPR15)

File Name:XBG-160-SPEC 2019-04-25

OVER CURRENT

95 ~ 108%

Constant current limiting, recovers automatically after fault condition is removed
