![MEAN WELL XBG-160-AB [3/8] Xbg 160](/img/pdf.png)
MEAN WELL XBG-160-AB [3/8] Xbg 160
![MEAN WELL XBG-160-AB [3/8] Xbg 160](/views2/1705216/page3/bg3.png)
2850mA, 56V
4100mA, 39V
4100mA, 34V
1425mA, 56V
2850mA, 34V
25V
30V
35V
40V
45V
50V
55V
60V
0mA 820mA 1640mA 2460mA 3280mA 4100mA
BLOCK DIAGRAM
PFC fosc : 45~50KHz
PWM fosc : 60~130KHz
160W Constant Power Mode LED Driver
XBG-160 series
File Name:XBG-160-SPEC 2019-04-25
(AB Type)
DETECTION
PWM
CIRCUIT/OTP
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
PFC
CIRCUIT
PFC
CONTROL
DRIVING METHODS OF LED MODULE
※ I-V Operating Area
◎ XBG-160
Operational Region
High Performance Region
DIM+
DIM-
O.C.P.
