MEAN WELL XLG-25-AB Datasheet онлайн
File Name:XLG-25-SPEC 2018-11-16
25W Constant Power Mode LED Driver
XLG-25 series
MM
110
IP67
SELV
Type HL
•LED street lighting
•LED architectural lighting
•LED bay lighting
•LED floodlighting
•Type HL for use in Class I, Division 2
hazardous (Classified) location.
XLG-25 series is a 25W AC/DC LED driver featuring the constant power mode output. XLG-25 operates
from 100~305VAC. Thanks to the high efficiency up to 88%, The entire series is able to operate between
-40 ~85 wide case temperature range with air convection. The design of metal housing and IP67℃℃
ingress protection level allows this series to fit both indoor and outdoor applications.XLG-25 is equipped
with various function options, such as dimming methodologies, so as to provide the optimal design
flexibility for LED lighting system.
•Constant Power mode output
•Metal housing design with functional Ground
•Built-in active PFC function
•Class 2 power unit
• <0.5WNo load / Standby power consumption
•IP67 rating for indoor or outdoor installations
•Function options: output adjustable via potentiometer
3 in 1 dimming (dim-to-off)
•Typical lifetime>50000 hours
•5 years warranty
Type
A
IP Level
IP67 Io adjustable through built in potentiometer.
Function Note
In Stock
AB IP67
3 in 1 dimming function (0~10Vdc, 10V PWM signal and resistance)
In Stock
05
■ Model Encoding
■ Description
■ Features ■ Applications
-XLG - 25
A
Rated wattage
Series name
Function mode option
I
｛
I: for India only
:None
Io adjustable through built in potentiometer
