75W Constant Power Mode LED Driver

XLG-75 series

File Name:XLG-75-SPEC 2019-04-09

■ Description

■ ModelEncoding

XLG - 75

Ratedwattage

Seriesname

XLG-75 series isa75W LED AC/DC driver featuring the constant power mode. XLG-75 operates from

100~305VAC and offers models with different rated current ranging between 700mA and 5000mA.

Thankstothehighefficiencyupto91%,withthefanlessdesign,theentireseriesisabletooperatefor

-40 ~+90 casetemperatureunderfreeairconvection.ThedesignofmetalhousingandIP67ingress℃ ℃

protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative

environment-adaptivecapabilityallowsthisseriestoreliablylightontheLEDsforallkindsofapplication

environments inalmost anyspots thatmayinstall LEDluminaires inthe world.XLG-75 series comply

with the latest version of IEC61347/GB7000.1-2015 and UL8750 international safety regulations. The

outputanddimmingcircuit are also completely in accordance with the new regulations with isolation to

ensure the safety of both userandluminairesystemduringinstallation.

Type

Ratedoutputvoltage(12/24VorL/Htypes)

Functionoptions

3in1dimmingfunction(0~10Vdc,10VPWMsignalandresistance)

InStock

Function

Note

InStock

Ioadjustableviabuilt-inpotentiometer

Ioadjustableviabuilt-inpotentiometer+

｛

I:forIndiaversion

:Forstandardversion

Note:12Vand24VmodelswithouttheABtype

M M

110

SELV

TypeHL

Note.12

•Skyscraperlighting

Streetlighting•

FloodlightLighting•

Stagelighting•

•Fishinglighting

Horticulturelighting •

•Baylighting

DMXpowersupply •

TypeHLforuseinclassⅠ,Division2 •

■ Features ■ Applications

•Wideinputrange100~305VAC(ClassⅠ)

•Fullpoweroutputat70~100%Constantpowermodeoperation

•MetalcasewithIP67,suitableforoutdoorapplication

•LVLEandClass2powerunit(exceptforLtype)

•Surgeprotectionwith6KV/4KV(10KV/6KVoptional)

•3in1dimmingfunction(DimtooffandIsolationdesign)

•India(EESL)versionwithInputOverVoltageProtectioncan

surviveinputvoltagestressof440Vacfor48hours

•Protectionfunctions:OVP/SCP/OCP/OTP

•Lifetime>50,000hrs.and5yearswarranty

Blank

IoandVofixed.(Forharshenvirenment)

Byrequest
