MODEL

OUTPUT

VOLTAGE RANGE Note.5

FREQUENCY RANGE

POWER FACTOR

EFFICIENCY (Typ.)

AC CURRENT

INPUT

INRUSH CURRENT(Typ.)

LEAKAGE CURRENT

EMC IMMUNITY

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

OVER TEMPERATURE

OVER VOLTAGE

500ms, 100ms/230VAC, 1200ms, 100ms/115VAC

10ms/ 230VAC 10ms/ 115VAC

47 ~ 63Hz

1.0A / 115VAC 0.45A / 230VAC 0.38A/277VAC

<0.75mA / 277VAC

20 ~ 95% RH non-condensing

-40 ~ +90℃, 10 ~ 95% RH

±0.03%/℃ (0 ~ 60℃)

10 ~ 500Hz, 5G 12min./1cycle, period for 72min. each along X, Y, Z axes

ENVIRONMENT

EMC EMISSION

SAFETY &

EMC

PROTECTION

Shut down output voltage, re-power on to recover

SHORT CIRCUIT

I/P-O/P:4.2KVAC I/P-FG:2.1KVAC O/P-FG:1.5KVAC

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

TOTAL HARMONIC DISTORTION

DC VOLTAGE

RATED CURRENT

RATED POWER

LINE REGULATION

LOAD REGULATION

SETUP, RISE TIME Note.6

HOLD UP TIME (Typ.)

RIPPLE & NOISE (max.) Note.3

VOLTAGE TOLERANCE Note.4

CONSTANT CURRENT REGION Note.2

OVER CURRENT

COLD START 50A(twidth=300 s measured at 50% Ipeak) at 230VACμ ; Per NEMA 410

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

9 units (circuit breaker of type B) / 14 units (circuit breaker of type C) at 230VAC

MAX. CASE TEMP.

Tcase=+90℃

(Please refer to "STATIC CHARACTERISTIC" section)

100 ~ 305VAC 142 ~ 431VDC

95 ~ 108%

Hiccup mode or Constant current limiting, recovers automatically after fault condition is removed

PF≧0.97/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC@full load

THD< 10%(@load≧50%/115VC,230VAC; @load≧75%/277VAC)

Tcase=-40 ~ +90℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)

XLG-75-12-

12V

150mVp-p

8.4~ 12V

60W

±3.0%

±0.5%

±2%

89%

13 ~ 19V

SAFETY STANDARDS

UL8750(type”HL”), UL879, CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384;

GB19510.1,GB19510.14; EAC TP TC 004; IP67 approved

XLG-75-24-

24V

3.1A

240mVp-p

16.8~ 24V

74.4W

±2.0%

±0.5%

±1%

90%

26 ~ 36V

NO LOAD

POWER CONSUMPTION

No load power consumption <0.5W(for standard version)

INPUT OVER VOLTAGE Note.7

320 ~ 370VAC (Shut down output voltage when the input voltage exceeds protection voltage)

can survive input voltage stress of 440Vac for 48 hours

CURRENT ADJ RANGE

2.5A~5A 1.55A~3.1A

Parameter

Conducted

Radiated

Harmonic Current

Voltage Flicker

EN61547

Parameter

ESD

Radiated

EFT/Burst

Surge

Conducted

Magnetic Field

Voltage Dips and Interruptions

Standard

EN61000-3-2

EN61000-3-3

Standard

EN61000-4-2

EN61000-4-3

EN61000-4-4

EN61000-4-5

EN61000-4-6

EN61000-4-8

EN61000-4-11

Test Level/Note

-----

Class C @load≥50%

-----

Test Level/Note

Level 3, 8KV air ; Level 2, 4KV contact

Level 3

4KV/Line-Line 6KV/Line-Earth(6K/10K option)

Level 3

Level 4

>95% dip 0.5 periods, 30% dip 25 periods,

>95% interruptions 250 periods

EN55015(CISPR15)

MTBF

DIMENSIONOTHERS

NOTE

PACKING

1.AllparametersNOTspeciallymentionedaremeasuredat230VACinput,ratedcurrentand25 ofambienttemperature.℃

2.Pleasereferto"DRIVINGMETHODSOFLEDMODULE".

3.Ripple&noisearemeasuredat20MHzofbandwidthbyusinga12"twistedpair-wireterminatedwitha0.1uf&47ufparallelcapacitor.

4.Tolerance:includessetuptolerance,lineregulationandloadregulation.

5.De-ratingmaybeneededunderlowinputvoltages.Pleasereferto“STATICCHARACTERISTIC”sectionsfordetails.

6.Lengthofsetuptimeismeasuredatfirstcoldstart.TurningON/OFFthedrivermayleadtoincreaseofthesetuptime.

7.OnlyforXLG-75Iseries

8.Thedriverisconsideredasacomponentthatwillbeoperatedincombinationwithfinalequipment.SinceEMCperformancewillbeaffectedbythe

completeinstallation,thefinalequipmentmanufacturersmustre-qualifyEMCDirectiveonthecompleteinstallationagain.

9.Thisseriesmeetsthetypicallifeexpectancyof>50,000hoursofoperationwhenTcase,particularlytcpoint(orTMP,perDLC),isabout75 orless.℃

10.PleaserefertothewarrantystatementonMEANWELL'swebsiteathttp://www.meanwell.com

11.Theambienttemperaturederatingof3.5℃/1000mwithfanlessmodelsandof5℃/1000mwithfanmodelsforoperatingaltitudehigherthan2000m(6500ft).

12.ProductssourcedfromtheAmericasregionsmaynothavethePSE/CCC/BIS/KClogo.PleasecontactyourMEANWELLsalesformoreinformation.

13.ForanyapplicationnoteandIPwaterprooffunctioninstallationcaution,pleasereferourusermanualbeforeusing.

https://www.meanwell.com/Upload/PDF/LED_EN.pdf

1232.28K hrs min. Telcordia SR-332 (Bellcore) ; 376.3Khrs min. MIL-HDBK-217F (25℃)

140*63*32mm (L*W*H)

0.58Kg;24pcs /15Kg /0.85CUFT

SPECIFICATION

File Name:XLG-75-SPEC 2019-04-09

75W Constant Power Mode LED Driver

XLG-75 series
