http://www.tracopower.com Page 1 of 3

AC/DC Power Supplies

TIW Series, 4 – 24 Watt

Features

◆

High efﬁciency switching power supplies

◆ Easy installation into standard ﬂush boxes

◆ Fully encapsulated plastic housing

◆ Dust and waterproof to IP 67

◆ Protection class ll

◆ Safety approval to IEC/EN 60950-1

EN 50178, EN 60335-1, UL 1310 class 2

◆ Approved for mounting onto wood or

materials with unknown ﬂammability

◆ Ready to meet ErP directive

◆ Universal input range 93 to 264 VAC

◆ Regulated output voltage

(models from 3.3 to 24 VDC)

◆ Operating temp. range –25°C to +50°C

◆ Short circuit and overload protection

◆ 3-year product warranty

The TIW series is a new range of small size DC-power supplies which have been

designed particularly for applications in home and ofﬁce installations.

The compact modules cases ﬁt in the standardized in-wall ﬂush boxes or also can

be mounted on walls. For connection there are models available with ﬂying wires

The power supplies comply fully with the safety and EMC standards requested for

commercial and residential class ll installations. Typical applications are powering of

electric devices used in home automation and in security systems like i.e. DC-motors,

controllers, indicators, etc.

Order Code Output Power max. Output Voltage Output Current Efﬁciency

TIW 06-103 4 W

3.3 VDC

1.2 A 75 %

TIW 06-105 5 W

5.0 VDC

1.0 A 75 %

TIW 06-106 6 W

6.0 VDC

1.0 A 80 %

TIW 12-112 12 W*

12 VDC

1.0 A 80 %

TIW 12-115 12 W*

15 VDC

0.8 A 80 %

TIW 12-124 12 W*

24 VDC

0.5 A 80 %

TIW 24-112 24 W*

12 VDC

2.0 A 83 %

TIW 24-124 24 W*

24 VDC

1.0 A 85 %

Models

(Mounted in standard ﬂush box)

Scheme

* If these models are used with 115 VAC input voltage, a 25% load reduction must be applied.

M M
