TRACO POWER TXLN 018-124 Datasheet онлайн
AC/DC Power Supply
TXLN 018 Series, 18 Watt
•
Compact metal case with screw terminal
block
•
Universal input 85-264 VAC
•
Convection cooled (no-fan)
•
High efficiency up to 85%
•
EMI/EMC compliance with EN
61000-6-3 and EN 61000-6-1
•
Compliance to EN 61000-3-2
•
Short circuit, overvoltage and overload
protection
•
IEC/EN/UL 62368-1 safety approvals
•
3 year product warranty
IEC 62368-1
UL 62368-1
The TXLN series is a family of encased power supplies designed for a wide
range of cost critical applications. With a low profile metal case and screw ter-
minal block connection, they are easy to install in any equipment. These power
supplies have universal input and comply with European EMC standards and
the Low Voltage Directive (LVD).
Models
Order Code
Output Power
max.
Output Voltage
nom. (adjustable)
Output Current
max.
Efficiency
typ.
TXLN 018-103
10 W
3.3 VDC (3.0 - 3.6 VDC)
3'000 mA
73 %
TXLN 018-105
15 W
5 VDC (4.5 - 5.5 VDC)
3'000 mA
78 %
TXLN 018-112
18 W
12 VDC (10.8 - 13.2 VDC)
1'500 mA
83 %
TXLN 018-115
15 VDC (13.5 - 16.5 VDC)
1'200 mA
84 %
TXLN 018-124
24 VDC (21.6 - 26.4 VDC)
750 mA
85 %
www.tracopower.com
January 22, 2021
Page 1 / 4
TENTATIVE
