TRACO POWER TXLN 018-124 [2/4] Tentative
![TRACO POWER TXLN 018-124 [2/4] Tentative](/views2/1707061/page2/bg2.png)
Input Voltage
- AC Range
85 - 264 VAC (Full Range)
- DC Range
120 - 375 VDC (Designed for, no certification)
Input Frequency
47 - 63 Hz
Input Current
- Full Load & Vin = 115 VAC
500 mA max.
Power Consumption
- At no load
150 mW max. (Ready to meet ErP directive)
Input Inrush Current
- At 230 VAC
50 A max.
- At 115 VAC
30 A max.
Recommended Input Fuse
(The need of an external fuse has to be assessed
in the final application.)
Input Specifications
Output Specifications
Output Voltage Adjustment
±10% (By trim potentiometer)
Output power must not exceed rated power!
Voltage Set Accuracy
±3% max. (3.3 Vout model)
±2% max. (5 Vout model)
±1% max. (other models)
Regulation
- Input Variation (Vmin - Vmax)
1.5% max. (3.3 Vout model)
1% max. (5 Vout model)
0.5% max. (other models)
- Load Variation (0 - 100%)
3% max. (3.3 Vout model)
2% max. (5 Vout model)
1% max. (other models)
Ripple and Noise
(20 MHz Bandwidth)
3.3 VDC model:
80 mVp-p max. (w/ 0.1 µF // 47 µF)
5 VDC model:
80 mVp-p max. (w/ 0.1 µF // 47 µF)
12 VDC model:
120 mVp-p max. (w/ 0.1 µF // 47 µF)
15 VDC model:
150 mVp-p max. (w/ 0.1 µF // 47 µF)
24 VDC model:
200 mVp-p max. (w/ 0.1 µF // 47 µF)
Minimum Load
Not required
Temperature Coefficient
±0.02 %/K max.
Hold-up Time
- At 230 VAC
60 ms min.
- At 115 VAC
16 ms min.
Start-up Time
- At 230 VAC
1'000 ms max.
- At 115 VAC
1'000 ms max.
Short Circuit Protection
Continuous, Automatic recovery
Output Current Limitation
105% typ. of Iout max.
Overvoltage Protection
115 - 140% of Vout nom.
Safety Standards
- IT / Multimedia Equipment
EN 62368-1
IEC 62368-1
UL 62368-1
- Certification Documents
www.tracopower.com/overview/txln018
Protection Class
Class I (Prepared): Connection to PE
Pollution Degree
PD 2
Over Voltage Category
OVC II
Safety Specifications
EMI Emissions
EN 61000-6-3 (Generic Residential)
- Conducted Emissions
EN 55032 class B (internal filter)
- Radiated Emissions
EN 55032 class B (internal filter)
- Harmonic Current Emissions
EN 61000-3-2, class A
- Voltage Fluctuations & Flicker
EN 61000-3-3
EMC Specifications
TXLN 018 Series, 18 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
January 22, 2021
Page 2 / 4
TENTATIVE
