TRACO POWER TXLN 035-212 [3/5] Txln 035 series 35 watt
![TRACO POWER TXLN 035-212 [3/5] Txln 035 series 35 watt](/views2/1707114/page3/bg3.png)
Minimum Load
- single output
3.3 VDC model:
0 % of Iout max.
5 VDC model:
0 % of Iout max.
7 VDC model:
0 % of Iout max.
12 VDC model:
0 % of Iout max.
15 VDC model:
0 % of Iout max.
24 VDC model:
0 % of Iout max.
30 VDC model:
0 % of Iout max.
48 VDC model:
0 % of Iout max.
- dual output
5 / 12 VDC model:
7.5 % of Iout max.
5 / 24 VDC model:
7.5 % of Iout max.
12 / -12 VDC model:
10 % of Iout max.
15 / -15 VDC model:
12.5 % of Iout max.
(dual output models require 300 mA on Output 1)
Temperature Coefficient
±0.02 %/K max.
Hold-up Time
- At 230 VAC
40 ms min.
- At 115 VAC
20 ms min.
Start-up Time
- At 230 VAC
1'000 ms max.
- At 115 VAC
1'000 ms max.
Short Circuit Protection
Continuous, Automatic recovery
Output Current Limitation
105 - 150% of Iout max.
Overvoltage Protection
115 - 140% of Vout nom.
(Output 1 only)
Safety Standards
- IT / Multimedia Equipment
EN 62368-1
UL 62368-1
- Certification Documents
www.tracopower.com/overview/txln035
Protection Class
Class I (Prepared): Connection to PE
Pollution Degree
PD 2
Over Voltage Category
OVC II
Safety Specifications
EMI Emissions
EN 61000-6-3 (Generic Residential)
- Conducted Emissions
EN 55032 class B (internal filter)
- Radiated Emissions
EN 55032 class B (internal filter)
- Harmonic Current Emissions
EN 61000-3-2, class A
- Voltage Fluctuations & Flicker
EN 61000-3-3
EMS Immunity
EN 55024 (IT Equipment)
- Electrostatic Discharge
Air:
EN 61000-4-2, ±8 kV, perf. criteria A
Contact:
EN 61000-4-2, ±4 kV, perf. criteria A
- RF Electromagnetic Field
EN 61000-4-3, 3 V/m, perf. criteria A
- EFT (Burst) / Surge
EN 61000-4-4, ±2 kV, perf. criteria A
L to L:
EN 61000-4-5, ±1 kV, perf. criteria A
L to PE:
EN 61000-4-5, ±2 kV, perf. criteria A
- Conducted RF Disturbances
EN 61000-4-6, 3 Vrms, perf. criteria A
- PF Magnetic Field
Continuous:
EN 61000-4-8, 3 A/m, perf. criteria A
- Voltage Dips & Interruptions
230 VAC / 50 Hz:
EN 61000-4-11
30%, 25 periods, perf. criteria A
>95%, 0.5 periods, perf. criteria A
>95%, 250 periods, perf. criteria C
EMC Specifications
Relative Humidity
90% max. (non condensing)
Temperature Ranges
- Operating Temperature
–20°C to +70°C
- Storage Temperature
–40°C to +85°C
General Specifications
TXLN 035 Series, 35 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
February 3, 2021
Page 3 / 5
