TRACO POWER TXLN 035-212 [4/5] Txln 035 series 35 watt
![TRACO POWER TXLN 035-212 [4/5] Txln 035 series 35 watt](/views2/1707114/page4/bg4.png)
Power Derating
- High Temperature
2.5 %/K above 50°C
- Low Input Voltage
0.83 %/V below 100 VAC
Cooling System
Natural convection (20 LFM)
Altitude During Operation
2'000 m max.
Switching Frequency
65 kHz typ. (PWM)
Insulation System
Reinforced Insulation
Working Voltage (rated)
275 VAC
Isolation Test Voltage
- Input to Output, 60 s
3'000 VAC
- Input to Case or PE, 60 s
1'500 VAC
- Output to Case or PE, 60 s
500 VAC
Isolation Resistance
- Input to Output, 500 VDC
100 MΩ min.
Leakage Current
(at 264 VAC)
- Touch Current
1000 µA max.
Reliability
- Calculated MTBF
400'000 h (single output models)
340'000 h (dual output models))
Housing Material
Aluminium
Connection Type
Screw Terminal
Weight
- single output
340 g
- dual output
350 g
Status Indicator
Indicated by green LED
Environmental Compliance
- REACH Declaration
www.tracopower.com/info/reach-declaration.pdf
REACH SVHC list compliant
REACH Annex XVII compliant
- RoHS Declaration
www.tracopower.com/info/rohs-declaration.pdf
Exemptions: 6a, 6b, 6c, 7a, 7c-I, 7c-II
Supporting Documents
Overview Link (for additional Documents)
www.tracopower.com/overview/txln035
TXLN 035 Series, 35 Watt
All specifications valid at nominal voltage, full load and +25°C after warm-up time unless otherwise stated.
www.tracopower.com
February 3, 2021
Page 4 / 5
