TRACO POWER TXLN 060-124 Datasheet онлайн
AC/DC Power Supply
TXLN 060 Series, 60 Watt
•
Compact metal case with screw terminal
block
•
Universal input 88-264 VAC
•
Convection cooled (no-fan)
•
High efficiency up to 86%
•
EMI/EMC compliance with EN
61000-6-3 and EN 61000-6-1
•
Compliance to EN 61000-3-2
•
Short circuit, overvoltage and overload
protection
•
IEC/EN/UL 62368-1 safety approvals
•
3 year product warranty
UL 62368-1
The TXLN series is a family of encased power supplies designed for a wide
range of cost critical applications. With a low profile metal case and screw ter-
minal block connection, they are easy to install in any equipment. These power
supplies have universal input and comply with European EMC standards and
the Low Voltage Directive (LVD).
Models
Order Code
Output Power
max.
Output Voltage
nom. (adjustable)
Output Current
max.
Efficiency
typ.
TXLN 060-103
40 W
3.3 VDC (3.0 - 3.6 VDC)
12'000 mA
72 %
TXLN 060-105
50 W
5 VDC (4.5 - 5.5 VDC)
10'000 mA
78 %
TXLN 060-112
60 W
12 VDC (10.8 - 13.2 VDC)
5'000 mA
81 %
TXLN 060-115
15 VDC (13.5 - 16.5 VDC)
4'000 mA
83 %
TXLN 060-124
24 VDC (21.6 - 26.4 VDC)
2'500 mA
84 %
TXLN 060-148
62 W
48 VDC (43.2 - 52.8 VDC)
1'300 mA
86 %
Options
on demand
(backorder with MOQ
non stocking item)
- Optional model with 7.5 VDC / 7'000 mA
- Optional model with 30 VDC / 2'000 mA
www.tracopower.com
February 3, 2021
Page 1 / 4
