APPENDIX I: Specicaons in Other Languages | 37
X470GTQ
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura AM4 Soporta AMD® serie A APU, Ryzen APU / CPU
Alimentación de Proyección Térmica (TDP – Thermal Design Power): 105Wa
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa AMD® X470
Memoria
Soporta DDR4 1866/2133/2400/2667/2933(OC)/3200(OC) Doble Canal
4x DDR4 DIMM Ranura de memoria Soporta hasta 64 GB Memoria
Cada DIMM soporta un modulo non-ECC 8/16 GB DDR4
* DDR4 - 2667 sólo para CPU Ryzen.
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 4x SATA III (6Gb/s) : Soporta AHCI & RAID 0,1,10
1x M.2 (M Key) : Soporta PCI-E 3.0 x4 (32Gb/s) & SATA III (6Gb/s) SSD
* M.2 : El ancho de banda depende de la CPU.
LAN
Realtek RTL 8118AS
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC887
Canales Audio de Alta Denición 7.1, Hi-Fi(Front)
USB
Ranura 2x USB 3.1 Gen2 (10Gb/s) - (2 en las entrada/salidas posteriores)
Ranura 6x USB 3.1 Gen1 (5Gb/s) - (4 en las entradas/salidas posteriores y 2 por los distribuidores internos)
Ranura 4x USB 2.0 (4 por los distribuidores internos)
Ranuras de Exnción
Ranura 2x PCIe 2.0 x1
Ranura 1x PCIe 2.0 x16 (x1)
Ranura 1x PCIe 3.0 x16 (El ancho de banda depende de la CPU)
Panel trasero de E/S
Teclado 1x PS/2
Ranura 1x DVI-D
Ranura 1x HDMI
Ranura 1x LAN
Ranura 2x USB 3.1 Gen2 (10Gb/s)
Ranura 4x USB 3.1 Gen1 (5Gb/s)
Socket audio 3x
Conectores en placa
Conector 4x SATA III 6Gb’s
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 1x USB 3.1 Gen1 (5Gb/s) -(cada distribuidor soporta 2 ranuras USB 3.1 Gen1)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x2
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Conector Externo S/PDIF x1
Distribuidor Ranura Serie x1
Distribuidor 5050 LED x2
Factor de Forma Factor de Forma uATX, 244 mm x 238 mm
Soporte OS
Windows 7(64bit) / 10(64bit)
Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
