Chapter 2: Hardware installaon | 19

X570GTA

2.8 LEDs

LEDs

Below LEDs are controlled by RACING GT EVO program. Please refer to Chapter 3.3 for more

detail soware seng.

RGB LED Device Header (5V/12V)
